Genuine BT Part #220310 BT Steer Axle

The steer wheel axle is held in place by an 8mm roll pin, on some models this is replaced with an M8 bolt and nyloc nut for addition security.

When installed, the steer wheels can be fitted on to the axle, attention should be paid to the area between the outer bearing in the steer wheel and the circlip groove, if there is sufficient space, a nylon spacer should be installed prior to the circlip. This prevents loads against the circlip caused by lateral movement of the steer wheel on the axle

Fits BT models L23, LHM, OEC, LEC

Part #5 on the diagram
